MUST ENERGY is a specialist deep cycle battery manufacturer in China. We offer customers a wide range of AGM VRLA batteries. Due to prominent features and advantages, this power supply device has found great popularity in various application fields and obtained high recognition among users.
Visits: 1
Models | Nominal voltage (V) | Capacity (Ah) | Overall dimensions (mm) | Weight (kg ± 3%) | Terminal | Layout | Bolt | |||
Length | Width | Height | Overall height | |||||||
FCD6-200 | 6 | 200/20HR | 306 | 168 | 220 | 225 | 30 | T5 | F | M8×16 |
FCD6-210 | 6 | 210/20HR | 260 | 180 | 247 | 252 | 29.5 | T5 | F | M8×16 |
FCD6-220 | 6 | 220/20HR | 306 | 168 | 220 | 225 | 31.5 | T5 | F | M8×16 |
FCD6-225 | 6 | 225/20HR | 243 | 187 | 275 | 275 | 30.5 | T5 | F | M8×16 |
FCD6-310 | 6 | 310/20HR | 295 | 178 | 354 | 360 | 46 | T5 | F | M8×16 |
FCD6-330 | 6 | 330/20HR | 295 | 178 | 354 | 360 | 46.6 | T6 | F | M8×16 |
FCD6-380 | 6 | 380/20HR | 295 | 178 | 404 | 410 | 55.3 | T5 | F | M8×16 |
FCD6-420 | 6 | 420/20HR | 295 | 178 | 404 | 410 | 56.8 | T6 | F | M8×16 |
FCD8-200 | 8 | 200/20HR | 260 | 182 | 295 | 301 | 39.0 | T5 | A | M8×16 |
FCD12-14 | 12 | 14/20HR | 152 | 99 | 96 | 102 | 3.8 | F1/F2 | D | / |
FCD12-20 | 12 | 20/20HR | 181 | 77 | 167 | 167 | 6 | T1 | B | M5×16 |
FCD12-24 | 12 | 24/20HR | 166 | 175 | 126 | 126 | 8.3 | T2 | B | M6×16 |
FCD12-26 | 12 | 26/20HR | 165 | 126 | 174 | 179 | 8.4 | T3 | B | M6×12 |
FCD12-35 | 12 | 35/20HR | 196 | 130 | 155 | 167 | 10.5 | T3 | A | M6×16 |
FCD12-40 | 12 | 40/20HR | 198 | 166 | 174 | 174 | 14.2 | T3 | B | M6×16 |
FCD12-55 | 12 | 55/20HR | 229 | 138 | 208 | 212 | 16.0 | T3 | B | M6×16 |
FCD12-70 | 12 | 70/20HR | 350 | 167 | 178 | 178 | 23.3 | T3 | B | M6×16 |
FCD12-75 | 12 | 75/20HR | 260 | 169 | 211 | 215 | 25 | T3 | A | M6×16 |
FCD12-85 | 12 | 85/20HR | 260 | 169 | 211 | 215 | 26.1 | T3 | A | M6×16 |
FCD12-90 | 12 | 90/20HR | 307 | 169 | 211 | 216 | 28.2 | T3 | A | M6×16 |
FCD12-100 | 12 | 100/20HR | 307 | 169 | 211 | 216 | 30.2 | T3 | A | M6×16 |
FCD12-110 | 12 | 110/20HR | 331 | 176 | 214 | 220 | 33.3 | T4 | A | M8×16 |
FCD12-120 | 12 | 120/20HR | 407 | 173 | 210 | 233 | 39.3 | T5 | A | M8×16 |
FCD12-135 | 12 | 135/20HR | 341 | 173 | 283 | 288 | 40.8 | T5 | B | M8×16 |
FCD12-150 | 12 | 150/20HR | 484 | 171 | 241 | 241 | 45.5 | T4 | A | M8×16 |
FCD12-180 | 12 | 180/20HR | 532 | 206 | 216 | 222 | 56 | T4 | C | M8×16 |
FCD12-200 | 12 | 200/20HR | 532 | 206 | 216 | 222 | 58.4 | T4 | C | M8×16 |
FCD12-220 | 12 | 220/20HR | 522 | 240 | 219 | 225 | 64.0 | T5 | C | M8×16 |
FCD12-240 | 12 | 240/20HR | 520 | 269 | 203 | 209 | 71 | T5 | C | M8×16 |
FCD12-260 | 12 | 260/20HR | 520 | 268 | 220 | 226 | 77 | T5 | C | M8×16 |
