Eaton 93PR UPS (25-200kW)
The 93PR UPS is developed by Eaton’s global team using Eaton’s patented advanced power electronics technology that meets military-grade requirements. This UPS amply satisfies power reliability requirements for data centers from small to large, automation or medical applications and IT infrastructure in network wiring closets.
Features:
- POWER RATING 25–200 kW
- UPS OUTPUT 380 / 400 / 415 V
- UPS TYPE Modular UPS
Visits: 8
Core features
Increased scalability
- Supports 8 units with different power modules in parallel for capacity up to 1.6 MW
- Provides an external battery cabinet and external battery shelf for customizable power supply solutions
- Maximizes system efficiency with Eaton’s patented three-level technology and ESS energy management system
- Provides efficiency up to 96.5% in double-conversion mode, and 99%+ in ESS mode
- Improves efficiency while reducing energy consumption and cooling requirements with VMMS intelligent module sleep function as an environment-friendly solution
- Enhances system reliability with a redundant design for key components such as fans and power supplies
- Minimizes failure rates with overall design, system testing, and comprehensive deployment
- Provides power and virtual system management with Intelligent Power Management (IPM) software
- Supports automatic storage of application data and safe shutdown of the operating system with Intelligent Power Protection (IPP) software
- Supports many communication accessories and ports
伊顿 93PR UPS—技术指标 |
|
|---|---|
| 产品快照 | |
| 功率等级 | 25–200 kW |
| 输出功率因数 | 1 |
| 额定电压 | 380, 400, 415 V |
| 频率 | 50 / 60 Hz |
| 效率 | 双变换效率高达 96.5% 交流直供效率大于 99% |
| UPS型号 | |
| Eaton 93PR | |
| 伊顿 93PR UPS 技术参数 | |
The 93PR UPS is developed by Eaton’s global team using Eaton’s patented advanced power electronics technology that meets military-grade requirements. This UPS amply satisfies power reliability requirements for data centers from small to large, automation or medical applications and IT infrastructure in network wiring closets.
