Three phase - Online UPS
Three phase - Online UPS
Embedded with isolation transformer, Giant series will eliminatecommon mode noise and the need to install expensive dedicatedcircuits. It provides reliable galvanically isolated power to criticaequipment.
Features:
- True online double conversion with DSP control
- Output power factor 0.9, customized up to 1.0
- Galvanic isolation eliminates common mode noise and provides the cleanest power in the most demanding conditions
- Conformal coating ensures operation stability and safety in critical environment
- Standard IP31 protection, optional IP42 to withstand harsh environment
- Sustains long-term operation for all types of loads under low input voltage
- Redundant design to quarantee product reliability
- Temperature compensation to prolong battery life
- Backfeed protection guarantees safety operation
- 7 touch co or lCD with customized contro setting and accessible informative data of the UPS
- Accepts dual-mains inputs
- Parallel capability up to 4 units
- Optional 40kA surge protection module
- Optional FOOTMASTER caster wheel available
Main Features
True online double conversion with DSP control
Output power factor 0.9, customized up to 1.0
Galvanic isolation eliminates common mode noise and provides the cleanest power in the most demanding
conditions
Conformal coating ensures operation stability and safety in critical environment
Standard IP31 protection, optional IP42 to withstand harsh environment
Sustains long-term operation for all types of loads under low input voltage
Redundant design to quarantee product reliability
Temperature compensation to prolong battery life
Backfeed protection guarantees safety operation
7 touch co or lCD with customized contro setting and accessible informative gata of the Ups
Accepts dual-mains inputs
Parallel capability up to 4 units
Optional 40kA surge protection module
Optional FOOTMASTER caster wheel available
